Cartesian: The Most Scalable Robot Technology
Cartesian Robots Offer Superior Precision Compared to Other Robot Types. Their Rigid Structure and Limited Range of Movement Enable Exceptional Accuracy.
Due to their simple design, low cost and scalability and the myriad of motor and control software solutions.
Easy to customize
Cartesian robots are easy to customize in terms of speed, precision and number of axes.
Cartesian robots are ideal for pick-and-place applications, which require only X, Y and Z axes.
Watch a short video about cartesian application
Cartesian robots, also known as gantry robots, are widely used in various industries for their precision, repeatability, and ability to handle heavy loads. In the context of wood cutting, Cartesian robots offer several advantages and can be integrated into automated woodworking processes.
Scalability and Customization
Cartesian Robots are Easily Scalable for Various Workspace Sizes and Customizable for Specific Applications. Their Modular Design Enables Simple Expansion and Modification.
High Precision and Accuracy
Their linear movement and rigid structure ensure precise positioning, making Cartesian robots ideal for high-accuracy applications like CNC machining, 3D printing, and assembly tasks.
Simple Control and Programming
Cartesian robots are highly scalable to accommodate various workspace sizes and customizable to meet specific application requirements. Their modular design supports easy expansion and modification.
Cartesian System: A Simplified Alternative to Traditional Robots
With their straightforward design and operation, Cartesian robots offer a more cost-effective solution compared to other industrial robots, particularly for applications that don’t require complex motion patterns or high-speed performance.
Learn from experts 📖
We manufacture a broad selection of 2- to 6-axis Cartesian robots designed to handle objects weighing from 2 kg to 180 kg.
Grow with confidence 📈
Cartesian robots offer a versatile and cost-effective automation solution with precise linear movement, making them ideal for a wide range of industrial applications.
Applications in Industry
The versatility, lower cost, and ease of programming make Cartesian robots viable for many applications in industrial settings. Let us have a look at some of them.
Pick and place
A single robotic arm can efficiently pick objects and sort them into different bins, streamlining the entire picking and sorting process.
Assembling system
Linear robots are ideal for automating repetitive assembly tasks, efficiently handling the consistent steps required to assemble product parts.
Palletizing and depalletizing
Cartesian robots can automate the processes of both placing products onto pallets and retrieving them from pallets.
Tim Klein
Operations Manager at NovaTech Solutions
"The Cartesian robot has drastically improved our production efficiency. It's fast, precise, and reliable. We couldn't be happier with our investment!"
Jannie Weber
Production Manager at Cebio sas
"I was impressed by how user-friendly the Cartesian robot is. The setup was straightforward, and the intuitive interface made it easy to program and operate."
Paul Richter
Operations Manager at Optima Logistics
"We love the versatility of our Cartesian robot. It's adaptable to various tasks, which has significantly increased our operational flexibility."
Ben Lehmann
Supply Chain Manager at Fiam srl
"The customer support of Logirobotix for the Cartesian robot has been exceptional. The team is responsive and knowledgeable, always ready to help us with any queries or issues."
The perfect robotics that aligns with our requirements.
"Investing in the Cartesian robot was a game-changer for us. Its innovative design and capabilities have set us ahead of the competition. We're thrilled with the results!"
Benefits of Cartesian Robots
Cartesian robots, also known as linear or gantry robots, offer several advantages in various industrial and manufacturing applications. Here are the key benefits:
Simplicity
Cartesian robots operate in a straightforward, linear fashion with movements along the X, Y, and Z axes.
High Precision and Accuracy
Their linear movement allow for precise positioning, making them ideal for applications requiring high accuracy.
Scalability and Customization
Cartesian robots can be easily scaled to fit different workspace sizes and customized to suit specific application.
Load Capacity
These robots can handle heavy loads efficiently due to their structure.
High Speed and Efficiency
With their linear motion, Cartesian robots can achieve high speeds and rapid acceleration.
Cost-Effectiveness
Cartesian robots are more affordable compared to other types of robots, such as SCARA or articulated robots.
Collaborative robots. Cobots
In industrial automation and quality control, Cartesian robots might not always be the best fit for every scenario. In these cases, collaborative robots (cobots) are often a preferred choice. Cobots are lightweight, compact, and easily re-deployable for various applications without needing changes to your production layout. Moving a cobot to new tasks is quick and simple, offering the flexibility to automate almost any manual process, including those with small batch sizes or rapid changeovers.
Simply move the robot arm to desired waypoints or touch the arrow keys on the easy-to-use touchscreen tablet.
Plug and Produce
An average setup time of just half a day with operator that can typically unpack the cobot in an hour.
Cobots are ideal for pick-and-place applications by automating almost all tasks
Testing cobots
Testing cobots for collision detection and safety is crucial to ensure they can operate safely alongside human workers.
Flexibility and Versatility
Cobots are highly adaptable and can be easily reprogrammed for different tasks. They can be quickly deployed to new workstations.
Scalability
Businesses can start with a single cobot and gradually scale up their automation efforts as needed and can be integrated into existing workflows.
Customization and Integration
Cobots can be customized with various end-effectors and accessories to suit specific applications. They can also be integrated with other automation systems.
Advantages of Cobots
When Cartesian robots are limited by their linear movement, workspace requirements, and lack of flexibility, cobots provide a versatile, safe, and collaborative solution for a wide range of industrial applications.
Flexibility
Cobots can perform a wide range of tasks, from simple pick-and-place to complex assembly operations. Easily reprogrammed for different tasks and product lines.
Adaptability
Can handle tasks in confined or dynamically changing environments. Suitable for tasks that involve variable geometry or require adaptability to different product types
Safety
Equipped with advanced sensors and force-limiting features to operate safely alongside human workers. Reduced need for extensive safety barriers and guarding.
Human Collaboration
Designed to augment human workers rather than replace them, enhancing productivity. Can assist with ergonomically challenging or repetitive tasks.
FAQ
Frequently Asked Questions (FAQ) about Cartesian Robots
What are the main applications of Cartesian Robots?
Cartesian robots are commonly used in applications such as:
Pick and place tasks
CNC machining
3D printing
Material handling
Assembly operations
Inspection and testing
How are Cartesian Robots controlled?
Cartesian robots are controlled using computer numerical control (CNC) systems or programmable logic controllers (PLCs). These systems coordinate the movement of each axis based on pre-programmed instructions, allowing for precise control over the robot's actions.
What industries commonly use Cartesian Robots?
Manufacturing: For assembly, machining, and material handling.
Electronics: For PCB assembly, testing, and inspection.
Automotive: For welding, part handling, and assembly.
Pharmaceutical: For laboratory automation, packaging, and material handling.
Food and Beverage: For packaging, palletizing, and material handling.
What are the key components of a Cartesian Robot?
Linear Actuators: Provide motion along the X, Y, and Z axes.
Controller: Manages the movement and operation of the robot.
End Effector: The tool or gripper attached to the robot's arm to interact with objects.
Frame: The rigid structure that supports the linear actuators and end effector.
How is the payload capacity determined for a Cartesian Robot?
The payload capacity is determined by the design and strength of the robot's actuators and frame. It varies depending on the model and manufacturer, and it's essential to select a robot that can handle the maximum load required for the intended application.
What factors should be considered when selecting a Cartesian Robot?
Workspace Requirements: Size and shape of the work area.
Payload: Maximum weight the robot needs to handle.
Precision: Required accuracy and repeatability.
Speed: Desired operational speed for tasks.
Integration: Compatibility with existing systems and processes.
Cost: Budget constraints and cost-effectiveness.
